Servo Motors / FeeTech 6V 2.2kg Digital 360 Servo

Description:

6V 2.2kg Digital 360 Degree Core Gear Servo by FeeTech
Gear Ratio: 1:263
Limit angle: No limit
Bearing: NO
Case: PC Plastic
Motor: Core Motor
The FeeTech 6V 2.2KG Digital 360 Degree Core Gear Servo comes with a core motor. It runs on an operating voltage range between 3 and 6 V and the no-load speed is 100 RPM / 60° at 6 V. The pulse width range between 1400 - 1600 μ sec.

What's Included:

1x FeeTech 6V 2.2kg Digital 360 Degree Core Gear Servo

Dimensions

Size: 22.5 x 12.1 x 26.7 mm (L x W x H)
Connector wire: 25 cm/p>

Specifications:

Gear Ratio: 1:263
Gear Type: POM
Limit angle: No limit
Bearing: No
Horn gear spline: 20T / 4.7 mm
Case: PC Plastic
Motor: Core Motor
Operating Voltage Range: 3 V - 6 V
Idle current (at stopped): 6 mA at 6 V
No-load speed: 100 RPM / 60° at 6 V
Running current (at no-load): 160 mA at 6 V
Peak stall torque: 2.2 kg.cm at 6 V
Rated torque: 0.7 kg.cm at 6 V
Stall current: 800 A at 6 V
Command Signal: Pulse width modification
Amplifier Type: Digital comparator
Pulse width range: 1400 - 1600 μ sec
Stop position: 1500 μ sec
Running degree: 360° continuous rotation (at 1400-1600 μ sec)
Dead band width: ≤90 μ sec
Rotating direction: Counterclockwise (1500-1600 μ sec)
Storage Temperature Range: -30 ~ 80 °C
Operating Temperature Range: -10 ~ 60 °C
Weight: 12.7± 1 g
